CONTROL SYSTEM
For Switzerland
Fill in the results into the official service
document for the periodical exhaust gas
controls, put stamp of your authorized
work shop, date of measurement and do
not forget to sign.
The official control stripe has to be stitched
at the right place into the exhaust gas
service document.
ADJUSTING THE START-IN-GEAR
PROTECTION DEVICE
1. Check:
ī
Start-in-gear protection device
operation
Incorrect
ī
Adjust.
2. Adjust:
ī
Start-in-gear protection cable.
Adjusting steps:
(1)Set the shift lever in the neutral
position.
(2)Loosen the locknut 1.
(3)Adjust the adjusting nut 2 so that the
point
a
on the wire connector 3
aligns with the mark
b
on the starter
cover.
(4)Tighten locknut 1.
NOTE:
Shift the shift lever into neutral and make
sure the starter can be pulled. If it cannot
be pulled, repeat the above procedure.
3-13
