Yamaha F6AMH Service Manual

THERMOSTAT, TIMING BELT AND GEARS
REMOVING THE TIMING BELT
Remove:
 Timing belt 1
NOTE:
Turn the drive gear 2 and align the “∆1”
mark on the driven gear 3 and “∆” mark
on the thermostat housing cover 4 (portin
a
).
REMOVING THE DRIVE GEAR
Remove:
 Drive gear nut
NOTE:
Loosen the drive gear nut with a 30 mm
deep socket
REMOVING THE DRIVEN GEAR
Remove:
 Driven gear bolt
A For USA and Canada
B Except for USA and Canada
Crankshaft holder:
YB-06561/90890-06561
Flywheel holder:
YB-06139/90890-06522
BA
5-31
