FUEL ENRICHMENT S
OLENOID (F8CW)
FUEL ENRICHMENT SOLENOID (F8C
W)
DISASSEMBLING
/ASSEMBLIN
G THE FUEL ENR
ICHMENT SOLENO
ID
Step
Job/Part
Q'ty
Remarks
1
Scr
ew (w
ith
washe
r)
4
2
Solenoid stay
1
3G
r
o
m
m
e
t
1
4
Wire pull hook
1
5
Plunger
1
6
Spring pin
1
Not r
eusa
ble
7
Link joint
1
8
Solenoid coil
1
For installa
tion, revers
e the removal
pro
ced
ure.
4-14
171
173
