POWER UNIT
REMOVING/INST
ALLING THE LEF
T SIDE EL
ECTRICAL COMPONENTS
2 (F8CW)
Step
Job/Part
Q'ty
Remar
ks
1C
l
a
m
p
1
Not reusab
le
2
Bolt (with wash
er)
2
Not reusab
le
3
Charge coil
1
2
leads (Blue, Brown)
4
Bolt (with wash
er)
4
Not reusab
le
5
Lighting coil
1
2
leads (Green x 2
)
6
Fuse holder
1
3
leads (Red x
3)
7S
c
r
e
w
2
8
Coupler clamp
1
9
Bolt (with wash
er)
2
10
Fuse holder stay
1
11
CDI unit
1
1
3 leads
For inst
allation, reverse t
he removal
procedure.
5-28
