MANUAL ST
ARTER
DISASSEMBLING/ASSEMBLING THE MANUAL S
T
ARTER
Step
Job/Part
Q'ty
Remarks
1
Wire assemb
ly
1
2
Return spri
ng
1
3S
c
r
e
w
1
4
Drive plate
1
5
D
rive s
pring
1
6
Sheave drum assem
bly
1
7
Circlip
1
8
Drive pawl
1
9
Return spri
ng
1
10
Spring
1
11
Sheave dra
m
1
12
Starter s
pring
1
13
Cover
Continued on
next page.
5-3
185
