POWER UNIT

DISCONNECTING/CONNECTING THE CABLES AND HOSE (F8CW)

Step Job/Part Q'ty Remarks

Engine oil drain Refer to “REPLACING THE ENGINE OIL” on

page 3-14.

1 Clip 1

2 Throttle cable 1

3 Oil level gauge 1

4 Water hose 1

For installation, reverse the removal

procedure.

5-16
