LOWER UNIT

REMOVING/INSTALLING THE LOWER UNIT (DUAL THRUST PROPELLER) (F8CW)

Step Job/Part Q'ty Remarks

1 Slit pin 1

2Nut 1

3 Plate washer 1

4 Propeller 1

5Spacer 1

6Bolt 1

7 Anode 1

8Screw 1

9Nut 1

10 Water inlet cover 2

11 Nut (short) 1

12 Nut (long) 1

13 Bolt (with washer) 4

Continued on next page.
