PROPELLER SHAFT HOUSING AND PROPELLER
SHAFT
DISASSEMBLING THE PROPELLER
SHAFT HOUSING ASSEMBLY
1. Remove:
ī
Ball bearing
A For USA and Canada
B Except for USA and Canada
2. Remove:
ī
Solid bushing
A For USA and Canada
B Except for USA and Canada
CHECKING THE REVERSE GEAR
Check:
ī
Teeth
Wear/damage
ī
Replace.
CHECKING THE BALL BEARING
Check:
ī
Ball bearing
Pitting/rumbling
ī
Replace.
NOTE:
Rotate the bearing and check if it turns
smoothly.
Slide hammer handle 1:
YB-06096
Stopper guide plate 2:
90890-06501
Bearing puller 3:
90890-06535
Stopper guide stand 4:
90890-06538
Drive rod:
YB-06229/90890-06652
Attachment:
YB-06298/90890-06649
A
B
6-14
