CYLINDER HEAD AND
OIL PUMP
CYLINDER HEAD AND OIL
PUMP
REMOVING/INST
ALLING THE CYLINDER
HEAD AND OIL PUMP
Step
Job/Part
Q'ty
Remarks
1
Spark plug
2
2
Oil filler
cap
1
3
O
-rin
g
1
25.0 x 3.
0 mm
4
Bolt (with washer)
4
5
Cylinder head cover
1
6
Cover seal
1
7
Screw (with wa
sher)
5
8
Breath
er cover
1
9
Cover gasket
1
Not reusable
10
B
olt (with washer)
3
11
B
olt (with washer)
4
12
B
olt (with washer)
2
13
Cylinder hea
d assembly
1
Continued on next page.
5-37
