UPPER CASE
DISASSEMBLING/AS
SEMBLING THE UPPER CASE
Step
Job/
Part
Q'ty
Remarks
1
Bolt (with washer)
2
2
Upper side mount rubber
1
3
Bolt (with washer)
2
4
Exhaust guide
1
5
Clip
1
6
Oil straine
r
1
7
Oil seal
1
Not reusa
ble
8G
a
s
k
e
t
1
Not reusa
ble
9P
i
n
2
10
Hose
1
11
Screw
1
12
Plate
1
13
Damper
1
Continued on next page.
7-23
409
