W
A
TER PUMP
W
A
TER PUMP
REMOVING/INST
ALLING THE W
A
TER PUMP
Step
Job/
Part
Q'ty
Remarks
1
W
ate
r seal rubber
1
2B
o
l
t
4
3P
l
a
t
e
2
4
W
ate
r pump
housing
1
5
Cartridge inse
rt
1
6
O-ring
1
54.5 x 3
.0 mm
Not reusable
7
Impeller
1
8
W
oodruff key
1
9B
o
l
t
2
10
Cartr
idg
e out
er pl
ate
1
11
Dowel p
in
2
For install
ation, reverse
the remova
l
procedure.
6-7
