MAINTE
NANCE SP
ECIFICA
TIO
NS
MAINTENANCE SPECIFICA
TIONS
BRACKET DIMENSIO
NS
Symbol
Unit
Model
W
orld wide
F6AMH, F6B
MH
F8CMH, F
8CW
USA, Canada
F6MH
F8MH
B1
mm (in)
70.5 (2.8)
B2
mm (in)
198 (7.8)
B3
mm (in)
95.3 (3.8)
B4
mm (in)
112 (4.4)
B5
mm (in)
105.3 (4.1
)
B6
mm (in)
207 (8.1)
B7
mm (
in)
—
B8
mm (
in)
—
B9
mm (in)
18 (0.7)
B10
mm (in
)
—
B11
mm (in
)
—
B12
mm (in
)
—
C1
mm (in)
28 (1.1)
C2
mm (in)
65 (2.6)
C3
mm (
in)
—
D1
mm (in)
8.3 (0.3)
D2
mm (in)
8.3 (0.3)
D3
mm (in)
—
D4
mm (in)
—
T1
mm (in)
—
2-21
79
81
