CLAMP BRACKET
CLAMP BRACKET
REMOVING/INST
ALLING THE CLAMP B
RACKET
Step
Job/Part
Q'ty
Remarks
1
T
ilt rod
1
2N
u
t
1
3
Plain washer
1
4B
o
l
t
1
5B
o
l
t
2
6
Cla
mp bracke
t cap
2
7
Clamp bracket plate
1
8
Through tube
1
9
Coller
1
10
Swivel br
acket
1
11
Bushing
2
12
Clamp bracket
1
13
Clamp bracket
1
Continued on
next page.
7-27
417
419
