Yamaha F6AMH - Installing the Muffler

UPPER CASE
INSTALLING THE OIL SEAL
Install:
 Oil seal
INSTALLING THE MUFFLER
Install:
 Muffler
NOTE:
 Apply Three Bond
®
1207B to
o
marked
portion of muffler installation and check
that there is no clearance after the muffler
is installed.
 Control the applied amount so that Three
Bond
®
1207B does not stick to the water
passage.
 Do not start the engine until 6 hours
elapse after application.
Driver rod:
YB-06071/90890-06604
Attachment:
YB-06112/90890-06614
7-25
