DRIVE SHAF
T AND FORW
ARD GEAR
INST
ALLING THE BALL BEARING
Insta
ll:
ī
Gear adjusti
ng shim(s)
ī
Ball bearin
g
A
For USA and Canada
B
Except for USA and Canada
NOTE:
Install the bal
l bearing with
its
manufacturerā
s mark facing
towards the
forward g
ear
.
Drive rod:
YB-06071/90890-06604
Attachmen
t:
YB-06167/90890-06634
6-19
