IGNITION SYSTEM
CHECKING THE CDI UNI
T
Measure:
ī
CDI unit out
put peak vol
tage
Below specification
ī
Replace the
CD
I unit.
NOTE:
Before measuring
CDI uni
t output pe
ak
voltage, make sure that no abnormality
is
observed on the charge coil and the pulser
coil.
CDI unit output peak volta
ge
Orange (O) - Black
(B)
r/min.
Cranking
1,500
3,5
00
Opened
Closed
D.C.V
53.2
1
40
16
8
168
Peak voltage adaptor:
YU-39991/90890-03172
8-13
455
