FUEL ENRICHMENT SOLENOID (F8CW)

ASSEMBLING THE FUEL ENRICHMENT

SOLENOID

Install:



Link joint 1



Plunger 2



Spring pin 3

NOTE:

Install link joint 1 so that it is in the

direction shown in the diagram in relation

with plunger 2 and solenoid coil 4.

ADJUSTING THE FUEL ENRICHMENT

SOLENOID

NOTE:

If the fuel enrichment solenoid has been

disassembled, adjust after installing it to

the intake system.

Adjust:



Fuel enrichment solenoid

Refer to “ADJUSTING THE FUEL

ENRICHMENT SOLENOID” on page

4-9.

4-15
