FUEL JOIN
T
, FUEL FI
L
TER AND
FUEL PUMP
FUEL JOINT
, FUEL FIL
TER AND FUEL PUMP
REMOVING/INST
ALLING THE FUEL JO
INT
, FUEL FIL
TER AND FUEL
PUMP
Step
Job/Part
Q'ty
Remarks
1
Clip
2
2
Fuel hose
1
3
Bolt (with washer)
1
4
Fuel joint
1
5
Clip
2
6
Fuel hose (with tube)
1
7
Fuel filter
1
8
Clip
1
9
Fuel hose (with tube)
1
10
Bolt (with washer)
2
11
Fuel pum
p assembly
1
12
O-ring
1
2.7 x 2.
3mm
Not r
eusa
ble
For instal
lation, reverse
the remov
al
procedure.
4-1
145
