FLYWHEEL ROTOR

FLYWHEEL ROTOR

REMOVING/INSTALLING THE FLYWHEEL ROTOR

Step Job/Part Q'ty Remarks

1Nut 1

2Washer 1

3 Flywheel rotor 1

4 Woodruff key 1

For installation, reverse the removal

procedure.

5-9
