OIL PUMP
OIL PUMP
DISASSEMBLING
/ASSEMBLING THE OIL
PUMP
Step
Job/Part
Q'ty
Remarks
1S
c
r
e
w
2
2
Pump co
ver
1
3
Cover gasket
1
Not reusable
4I
n
n
e
r
r
o
t
o
r
1
5S
h
a
f
t
1
6P
i
n
1
7O
u
t
e
r
r
o
t
o
r
1
8
Oil pump housing
1
For installation, r
everse the removal
procedure.
5-41
