CLAMP BRACKET

INSTALLING THE CLAMP BRACKET

PLATE

Install:



Clamp bracket plate 1

NOTE:

Turn clamp bracket plate 1 down until it

contacts stopper boss 2 of the clamp

bracket.

7-29
