CARBURETOR
CARBURETOR
DISASSEMBLING/AS
SEMBLING THE CARBURETO
R
Step
Job/Part
Q'ty
Remarks
1
Drain plug
1
2
Gasket
1
Not r
eusa
ble
3
Throttle stop screw
1
4S
p
r
i
n
g
1
5S
c
r
e
w
1
6
Screw
(with washer)
1
7
Cover plate
1
8
Cover gaske
t
1
Not r
eusa
ble
9
Pilot screw
1
10
Screw (
with w
ashe
r)
1
11
Float c
hamber
1
12
O-ring
1
48 x 1.
8 mm
Not r
eusa
ble
13
Float p
in
1
Continued on
next page.
4-10
