INT
AKE SYSTEM
REMOVING/INST
ALLING THE INT
AKE SYSTEM (F8C
W)
Step
Job/Part
Q'ty
Remarks
Manual starter
Refer to “REMOVING/INST
ALLING THE
MANUAL ST
ARTER” on page 5-1.
Flywheel r
otor
Refer to “REMOV
ING/INST
ALLING THE
FL
YWHEEL ROTOR” on page 5-9.
1
Brea
ther hose
1
2
W
a
ter pilo
t hose
1
3
Throttle axle link
1
4
Choke rod
1
5
Li
nk jo
int
1
6
Choke knob
1
7
O-ring
1
3.0 x 1
.1 mm
Not r
eusa
ble
8
Solenoid connector
1
9
Bolt (with washer)
2
10
Clamp
1
Continued on
next page.
4-7
157
