STEERING HAND
LE
STEERING HANDLE
REMOVING/INST
ALLING THE STEERING HANDLE (SHOR
T HANDLE OF F6AMH,
F6BMH,
F8CM
H)
Step
Job/Part
Q'ty
Remarks
1
Throttle cable
2
2
Stop switch lead
2
3
Gr
ommet
1
4
Bolt (with washer)
1
5P
l
a
t
e
1
6
Bushing
1
7
Steering handle assembly
1
8
Plate washer
1
9
W
a
ve washer
1
10
Bushing
1
11
Grommet
1
12
Nut
2
13
Bracket
1
Continued on
next page.
7-1
