Yamaha F6AMH - Checking the Coller; Checking the Shift Cam; Disassembling the Bearing Housing; Removing the Solid Bushing

BEARING HOUSING, SHIFT CAM AND LOWER
CASE
REMOVING THE SOLID BUSHING
Remove:
 Solid bushing
A For USA and Canada
B Except for USA and Canada
DISASSEMBLING THE BEARING
HOUSING
Remove:
 Solid bushing
A For USA and Canada
B Except for USA and Canada
CHECKING THE COLLER
Check:
 Collar
Damage/wear
 Replace.
CHECKING THE SHIFT CAM
Check:
 Shift cam
Damage/wear
 Replace.
CHECKING THE LOWER CASE
1. Clean:
 Lower case (with a soft grush and
solvent).
Driver rod:
YB-06229/90890-06652
Attachment:
YB-06028/90890-06650
Driver rod:
YB-06229/90890-06652
Bushing attachment:
YB-06028/90890-06650
6-21
