POWER UNIT/C
OOLING SYS
TEM
CHECKING THE TIMING BEL
T
1.
Remove:
ī
Recoil starter
1
ī
Dust cover
2
2.
Check:
ī
T
iming belt
W
ear/damage
ī
Replace.
NOTE:
Install
the timing
belt with
the part
name
facing up.
3.
Install:
ī
Dust cover
2
ī
Recoil starter
1
POWER UNIT/COO
LING SYSTEM
CHECKING THE COOL
ING W
A
TER
DISCHARGE
Check:
ī
Cooling water discharge
Dose not
flow
ī
Clean and c
heck the
cooling water passage.
Checking steps:
(1)
Place the lower
unit
in water
.
(2)
Start the engine.
(3)
Check that water fl
ows from the pilot
water
outlet.
3-19
127
129
