Yamaha F6AMH - Removing;Installing the Shift Lever

SHIFT LEVER
SHIFT LEVER
REMOVING/INSTALLING THE SHIFT LEVER (SHORT HANDLE AND REMOTE OF
F6AMH, F6BMH, F8CMH, F8CW)
Step Job/Part Q'ty Remarks
1 Bolt 1 (F8CW only)
2 Battery (+) cable 1 (F8CW only)
3 Starter relay 1 (F8CW only)
4 Rubber stay 1 (F8CW only)
5 Clamp 1 (F8CW only)
6 Bolt (tapping) 1 (F8CW only)
7 Starter relay bracket 1 (F8CW only)
8 Bolt (tapping) 1 (F6AMH, F6BMH, F8CMH only)
9 Manual starter cable bracket 1 (F6AMH, F6BMH, F8CMH only)
10 Bolt 2 (F8CW only)
11 Neutral switch bracket 1 (F8CW only)
12 Nut 1
13 Clip 1
Continued on next page.
7-13
