PROPELLER SHAF
T HOUSING AND PROPELLER
SHAF
T
DISASSEMBLING/ASSEMBLING THE PRO
PELLER SHAF
T HOUSING ASSEMBL
Y
Step
Job/Part
Q'ty
Remarks
1
Revers
e gear
1
2
Gear adjust
ing shim
*
3
O-ring
1
51.0 x
3.1 mm
Not r
eusa
ble
4
O-ring
1
55.4 x
1.9 mm
Not r
eusa
ble
5
Ball beari
ng
1
6
Oil seal
2
Not r
eusa
ble
7
Solid bushing
1
8
Propeller shaft housing
1
For instal
lation, reverse
the remov
al
procedure.
*: as r
equired
6-13
