POWER UNIT

DISCONNECTING/CONNECTING THE ELECTRICAL LEADS (F6AMH/F6MH, F6BMH,

F8CMH/F8MH)

Step Job/Part Q'ty Remarks

1 Bolt (with washer) 1

2 Engine stop switch connector and

terminal

2White, Black

3 Emergency signal light connector 2 Yellow/red, Pink

For installation, reverse the removal

procedure.
