CAMSHAFT AND VALVES
INSTALLING THE VALVE
Install:
 Intake valve or exhaust valve 5
 Valve spring seat 4
 Valve spring 3
 Valve spring retainer 2
 Valve spring lock 1
NOTE:
 Set the attachment on to the center of the
spring retainer.
 Do not overtighten the valve spring
compressor.
INSTALLING THE CAMSHAFT OIL SEAL
Install:
 Cam shaft oil seal 1
A For USA and Canada
B Except for USA and Canada
NOTE:
Press fit the oil seal to the stepped portion
of the cylinder head and check that it is not
at an angle.
Valve spring compressor:
YM-01253/90890-04019
Attachment:
YM-04108/90890-04108
Driver rod:
YM-06229/90890-06652
Attachment:
YB-06197/90890-06653
5-51
