PROPELLER SHAFT HOUSING AND PROPELLER

SHAFT

INSTALLING THE PROPELLER SHAFT

HOUSING ASSEMBLY

Install:



Propeller shaft housing assembly

NOTE:

Install the propeller shaft housing

assembly with the arrow mark facing up.
