LOWER UNIT

INSTALLING THE PROPELLER

Install:



Propeller

WARNING

Do not hold the propeller with your hands

when removing or installing it. Be sure to

remove the battery leads from the

batteries and the lanyard engine stop

swith. Put a block of wood between the

cavitation plate and propeller to keep the

propeller from turning.

6-6
