UPPER CASE
UPPER CASE
REMOVING/INST
ALLING THE UPPER CASE
Step
Job/Part
Q'ty
Remarks
1
W
ater tube
1
2
W
ater sea
l rubber
1
3
Bolt (with washer)
2
4
Bolt (with washer)
2
5N
u
t
4
6
Lower mount rubber housing
2
7
Lower front mount rubber
1
8
Lower side mount rubber
2
9S
c
r
e
w
1
10
Nut
2
11
Plate
1
12
Upp
er case
1
For insta
llation, reverse th
e removal
procedure.
7-21
