DRIVE SHAF
T AND FORW
ARD GEAR
DRIVE SHAF
T AND FOR
WARD
GEAR
REMOVING/INST
ALLING THE DRIVE SHAF
T AND FORW
ARD GEAR
Step
Job/Part
Q'ty
Remarks
1
Circlip
1
2
Pinion
1
3
Pinion adjusting shim
*
4D
r
i
v
e
s
h
a
f
t
1
5F
o
r
w
a
r
d
g
e
a
r
1
6
Ball bearing
1
7
Ge
ar ad
justing sh
im
*
For insta
llation, reverse th
e removal
procedure.
*: as r
equired
6-17
341
