16 Remote control
122 PM5D/PM5D-RH Owner’s Manual Operating section
Transmitting MIDI events when you switch scenes
You can register a desired MIDI message for each scene in scene memory so that this message will be transmitted from the
MIDI OUT connector when you recall the scene. For example you can use this to switch programs on an external MIDI-com-
patible effect processor when the scene changes.
1
Connect the MIDI OUT connector of the PM5D
to the MIDI IN connector of the external
device.
2
In the DISPLAY ACCESS section, press the
[SCENE] key several times to access the SCENE
screen shown below.
3
Scroll the scene list upward or downward to
select the scene number for which you want to
assign a MIDI event.
4
Scroll the scene list toward the right to dis-
play the MIDI EVENT column.
In the MIDI EVENT column you will input the MIDI
message that will be transmitted when you recall that
scene.
5
Click the button at the left edge of the MIDI
EVENT column to open the MIDI EVENT SETUP
window.
6
Use the MIDI EVENT SETUP window to specify
the MIDI message that will be linked with that
scene.
The procedure for specifying a MIDI message in the
MIDI EVENT SETUP window is the same as in the
MIDI REMOTE screen MIDI REMOTE SETUP win-
dow, with the exceptions that you cannot select FAD,
ENC, or SW for the DATA 1/DATA 2 boxes, and that
there is no LEARN button. (For details, refer to ➥
p.118) When you have finished making settings, click
the OK button in the MIDI EVENT SETUP window.
7
Click the Tx ON/OFF
column located at the
right of the MIDI EVENT
column to turn it on.
The MIDI event linked to
the corresponding scene is
now enabled.
8
In the same way, specify MIDI events for other
scene numbers.
9
Recall a scene to which a MIDI event is linked.
The MIDI message will be transmitted from the speci-
fied MIDI port.
SCENE
MIDI EVENT column
To Next Page
