PM5D/PM5D-RH Owner’s Manual Reference section 219
Information shown
in the display
Function
menu
Global
functions
Output
functions
Input
functions
Appendices
H INPUT SOLO SAFE
Here you can specify input channels that will be
excluded from Solo operations. (You can specify more
than one.) The buttons correspond to the following
input channels.
I OUTPUT SOLO SAFE
Here you can specify output channels that will be
excluded from Solo operations. (You can specify more
than one.) The buttons correspond to the following
output channels.
Hint
Solo Safe settings and Cue on/off operations are linked for
paired channels. Solo Safe operations can be performed inde-
pendently of the scene memory.
J Level meter
This is a peak level meter that indicates the level of the
signals output from the CUE OUT jacks. You can select
the level detection point to be immediately befor the
delay that is provided on the MONITOR/CUE bus
output (when the PRE DELAY button is on), or imme-
diately after the delay (when the POST DELAY button
is on).
K MONITOR / CUE DELAY
Here you can make settings for the delay function pro-
vided on the MONITOR/CUE bus output. Use the
knob to specify the delay time (0–1000 msec), and use
the DELAY button to switch the delay on/off. In gen-
eral, this is linked with the MONITOR/CUE DELAY
setting in the MONITOR screen. However, the differ-
ence is that in this screen, turning the AUTO BYPASS
button on lets you automatically bypass the delay when
you perform the Cue any input channels.
INPUT 1–48 Input channels 1–48
ST IN 1–4 ST IN channels 1–4
FX RTN 1–4 FX RTN channels 1–4
SET ALL
Sets all input channels to the Solo
Safe condition
CLEAR ALL
Defeats the Solo Safe setting for
all input channels
MIX 1–24 MIX channels 1–24
MATRIX 1–8 MATRIX channels 1–8
STEREO A/B STEREO A/B channels
SET ALL
Sets all output channels to the
Solo Safe condition
CLEAR ALL
Defeats the Solo Safe setting for
all output channels
8
9
J
K
