Yamaha PM5D - Other Functions

Other Functions
354 PM5D/PM5D-RH Owner’s Manual Reference section
Other Functions
❏ Libraries
❏ Input Function
❏ Output Function
❏ Processor
Name Number Total
Scene Memory Preset 1 + User 500 501
Input Patch Library Preset 1 + User 99 100
Output Patch Library Preset 1 + User 99 100
Input Channel Library Preset 1 + User 199 200
Output Channel Library Preset 1 + User 199 200
Input EQ Library Preset 40 + User 159 199
Output EQ Library Preset 3 + User 196 199
GATE Library Preset 4 + User 195 199
COMP Library Preset 36 + User 163 199
Effect Library Preset 54 + User 145 199
GEQ Library Preset 1 + User 199 200
HA Library Preset 1 + User 199 200
Function Parameter
Phase Normal/Reverse
MS Decode On, S-Gain
Attenuator –96 to +24 dB
HPF
Slope= 12 dB/Oct
Frequency= 20 Hz to 600 Hz
4Band Equalizer
Frequency= 20 Hz to 20 kHz
Gain= –18 dB to +18 dB
Q= 0.10 to 10.0
Low Shelving (Low Band)
High Shelving, LPF (High Band)
Type I/Type II
Insert Insert Point: Pre EQ/Post EQ/Pre Delay/Post Fader
Direct Out
Direct Out Point: Pre HPF/Pre EQ/Pre Fader/Post
On
Noise Gate
Type: Gate/Ducking
Threshold= –54 dB to 0 dB
Attack= 0 msec to 120 msec
Hold= 0.02 msec to 1.96 sec
Decay= 5 msec to 42.3 sec
Range= –70 dB to 0 dB
Key In: Self Pre EQ/Self Post EQ/Mix21-24/
Ch1-STIN4R (8ch block)
Key In Filter: HPF/LPF/BPF
Compressor
Type: Comp/Expander/Compander H/
Compander S
Threshold= –54 dB to 0 dB
Ratio= 1:1 to ∞:1
Attack= 0 msec to 120 msec
Release= 5 msec to 42.3 sec
Gain= 0 dB to +18 dB
Knee= Hard to 5 (soft)
Input Delay Time= 0.0 msec to 1000 msec
Fader Level: 1024 steps, ∞, –138 dB to +10 dB
On On/Off
DCA Group 8 Groups
Mute Group 8 Groups
Mix Send
24 sends
Fix/Variable can be set each two mixes
Mix Send Point: Pre EQ/Pre Fader/Post On/Post
TO ST
Level: 1024 steps, ∞, –138 dB to +10 dB
LCR Pan CSR= 0% to 100%
Surround Pan 3-1, 5.1, 6.1 panning support
Function Parameter
8Band Equalizer
(Matrix: 4band)
Frequency= 20 Hz to 20 kHz
Gain= –18 dB to +18 dB
Q= 0.10 to 10.0
Low Shelving (Low Band)
High Shelving, LPF (High Band)
Type I/Type II
Insert Insert Point: Pre EQ/Post EQ/Pre Fader/Post On
Compressor
Type: Comp/Expander/Compander H/Com-
pander S
Threshold= –54 dB to 0 dB
Ratio= 1:1 to ∞:1
Attack= 0 msec to 120 msec
Release= 5 msec to 42.3 sec
Gain= 0 dB to +18 dB
Knee= Hard to 5 (soft)
Input Delay Time = 0.0 msec to 1000 msec
Fader Level: 1024 steps, ∞, –138 dB to +10 dB
On On/Off
DCA Group 2 Groups
Mute Group 8 Groups
Mix to Matrix
Stereo to Matrix
Matrix Send Point: Pre Fader/Post Fader/Post On
Level: 1024 steps, ∞, –138 dB to +10 dB
Output Port Att 0 dB to –9 dB
Function Parameter
GEQ 31 bands x 12 systems
Effects Stereo In/Stereo Out multi effector x 8 systems
