PM5D/PM5D-RH Owner’s Manual Reference section 197
Information shown
in the display
Function
menu
Global
functions
Output
functions
Input
functions
Appendices
❏ CSV IMPORT mode
If a CSV file or directory is selected, CSV IMPORT
mode will be selected automatically. The selected CSV
file (or CSV files in the selected directory) will be
searched, and the following items will appear in the
right of the screen.
J LIBRARY TITLE
K CHANNEL NAME
Use these buttons to select the data you want to load
(e.g., library titles or channel names). (The contents of
each item are the same as in the SAVE screen.)
However, you will only be able to select items that
match the CSV file (or the CSV files in the directory)
selected in the list for loading. The buttons for other
items will be grayed-out and unavailable.
L SET ALL
This button selects all available items for loading.
M CLEAR ALL
De-selects all items.
Note
Note that the screen will automatically switch to CSV IMPORT
mode even if the directory selected in the list does not contain
an appropriate CSV file. (In this case, all buttons will be
grayed-out.)
Here you can assign the desired input channels / output
channels to the eight faders in the DCA section of the
panel.
A FADER MODE
Indicates the currently selected
fader mode (DCA, layer A–F).
You can also click the buttons to
switch the fader mode directly.
B Faders 1–8
The parameter assigned to each
fader of the DCA fader section is
shown here. This will depend on
the FADER MODE (
1) and
channel selection (
3). You can
also operate the fader directly by
dragging it upward or downward.
C Channel selection
This indicates the channel that is
assigned to each fader in layers A–
F, and its name (only for input
channels). Click the / but-
tons at left and right to change the
assignment. You can choose from
CH 1–48, ST IN 1L–ST IN 4R, FXRTN 1L–FXRTN 4R,
MATRIX 1–8, MIX 1–24, and DCA 1–8.
L
M
K
J
FADER ASSIGN screen
1
2
3
