Channel parameter behavior when paired
This table lists the behavior of channel parameters when INPUT/ST IN channels, MIX channels, or MATRIX channels are
paired.
❏ Parameters that are copied when pair-
ing is enabled
❏ Parameters that are turned on when
pairing is enabled
❏ Parameters that are not modified when
pairing is enabled (reset if RESET BOTH
is selected)
❏ Parameters that are not modified when
pairing is enabled (not reset even if
RESET BOTH is selected)
INPUT/ST IN MIX MATRIX
LCR On/Off
LCR Center-Side Ratio
Fade Time On/Off
Fade Time Start Offset
Fade Time Fading Time
Insert In On/Off
Insert Point
Direct Out On/Off
Direct Out Point
On/Off
Level Master Level
GATE On/Off
GATE Key In Source
GATE Key In Filter On
GATE Filter Type
GATE Filter Freq.
GATE Filter Q
GATE Type
GATE Attack
GATE Range
GATE Hold
GATE Decay
GATE Threshold
COMP LINK 1-8 COMP LINK A-H
COMP On/Off
COMP Key In Source
COMP Key In Type
COMP Attack
COMP Release
COMP Ratio
COMP OutGain
COMP Knee/Width
COMP Threshold
EQ LINK 1-8 EQ LINK A-F EQ LINK G,H
HPF On/Off EQ HPF On/Off x2 EQ HPF On/Off
HPF Freq
EQ Type 1,2
EQ On/Off
EQ Filter Type x2 EQ Filter Type x4 EQ Filter Type x2
EQ LPF On/Off EQ LPF On/Off x2 EQ LPF On/Off
EQ Q x4 EQ Q x8 EQ Q x4
EQ Freq x4 EQ Freq x8 EQ Freq x4
EQ Gain x4 EQ Gain x8 EQ Gain x4
EQ Bypass x8 EQ Bypass x4
Delay On/Off
Surround LFE
Surround Div.
Surround Div.Rear
Surround Div.Link
Mute Group 1-8 On/Off
DCA Group 1-8 On/Off DCA Group 7,8 On/Off
To Stereo On/Off
To Stereo Point
Mix Send Pre Point Mix Send Post Point
Mix Send Follow Pan Vari
Mix Send Follow Pan
Fixed
Mix Send 1-24 On/Off
Mix Send 1-24 Pre/Post
Mix Send 1-24 Level
To Matrix On/Off
To Matrix Point
Selective Recall On
Selective Recall Parameter
Recall Safe On
Recall Safe Parameter
Mute Safe On
Tracking On/Off
Tracking Level
Solo Safe On/Off
Cue/Solo On/Off
CH COPY CH SELECT
GLOBAL PASTE CH SELECT
INPUT/ST IN MIX MATRIX
Attenuator Gang
Gate Stereo Link
Comp Stereo Link
Delay Gang
INPUT/ST IN MIX MATRIX
Phase
To Stereo Pan
Master Balance
Attenuator
Delay Time
Surround LR Pan
Surround FR Pan
Mix Send 1-24 Pan
To Matrix 1-8 Level
To Matrix 1-8 Pan
Input Pan Mode
Surround Link On/Off
Surround Link Pattern
M-S Encode On/Off
M-S Encode S-Gain
INPUT/ST IN MIX MATRIX
Mix Type
(VARI,FIX,SURR)
TB On/Off
OSC On/Off
MONITOR DEFINE On/Off
INPUT/ST IN MIX MATRIX
To Next Page
