SCENE function
166 PM5D/PM5D-RH Owner’s Manual Reference section
Here you can specify parameters/channels that will be
excluded from recall operations for all scenes.
A HA SAFE ON/OFF (Head Amp safe on/off)
buttons
These buttons select the channels whose assigned HA
(Head Amp) will be excluded from recall operations.
Note
If you scroll the scroll bar downward, you will see that the CH
column of the SAFE PARAMETERS area shows not only
input channels but also the following input ports.
AD1-AD48 . . . . INPUT jacks 1-48
AD1L-AD4R . . L/R channels of ST IN jacks 1-4
ExHA1-1–ExHA8-8 . . . . Channels 1-8 of external head amps
1-8 (AD8HR or AD824)
B CH SAFE ON/OFF (Channel safe on/off)
buttons
These buttons select the channels that will be excluded
from recall operations. These are linked with the
[RECALL SAFE] key of the panel.
C Parameter matrix grid
Here you can select the channel parameters that will be
excluded from recall operations. If the ALL button is
on, all parameters except for CH to MIX will be
excluded.
Recall Safe and Selective Recall can be used together.
Channels/parameters excluded from recall operations
by either Recall Safe or Selective Recall (or both) will
not be recalled.
Note
Settings in the parameter matrix grid are ignored for channels
whose CH SAFE ON/OFF button is OFF.
D ASSIGN
This area indicates the number of assigned channels for
each parameter.
E SET ALL
These buttons turn on the buttons of all channels or all
buttons of the corresponding parameter.
F CLEAR ALL
These buttons turn off the buttons of all channels or all
buttons of the corresponding parameter.
G SELECTIVE RECALL PARAMETERS PASTE
This button copies parameter settings from the SELEC-
TIVE RECALL screen, and pastes them into the
RECALL SAFE screen. When you click the button, a
confirmation message will appear.
H OTHER SAFE PARAMETERS
By using these buttons, parameters other than those
described above can be excluded from recall
operations.
I SET ALL
This button turns on all buttons of the OTHER SAFE
PARAMETERS area.
J CLEAR ALL
This button turns off all buttons of the OTHER SAFE
PARAMETERS area.
RECALL SAFE screen
RECALL SAFE
5
4
6
8
9
7
J
To Next Page
