Ventilation
134 Instructions for Use Apollo SW 4.5n
Part Number: 9053586, 3rd edition
Starting Volume Mode AutoFlow
Presetting the Volume AutoFlow ventilation mode
Figure 69. Volume AF ScreenPrior to activating Volume AF, the user can preset
the Volume AF parameters.
1. Press the >Vol. AF Mode< key located at the
bottom of the display panel (1 in Figure 69). The
LED on the key and the status field at the top of
the screen (2 in Figure 69) flash on and off.
The row of buttons for the ventilation parameters
valid for Volume AF are displayed with a light green
background (3 in Figure 69). This means that they
are not yet active.
2. Press the button for the parameter to be
changed; its color changes to yellow to indicate
that it is selected.
3. Turn the rotary knob to adjust the parameter to
the desired value, and press the rotary knob to
confirm (4 in Figure 69).
Continue to set the values for the other parameters.
