Monitoring
Instructions for Use Apollo SW 4.5n 159
Part Number: 9053586, 3rd edition
–MVSPON spontaneously breathed expiratory
minute volume
–MV
MAND mandatory breathed expiratory
minute volume
–C
PAT
*
(patient lung compliance) (only on data
screen)
– Trend curve for MV and C
PAT
–VT bar graph
*
CPAT = with mandatory breaths.
SpO2 concentration (Optional)
– Curve display (plethysmogram)
– Numerical display:
–SpO
2 (functional O2 saturation level of blood)
– ♥ (pulse rate)
– Trend curve for SpO
2 and pulse
Loops (Optional)
Graphical display for the following measured and
calculated values:
– Pressure/Volume
– Flow/Volume
See “Loops (Optional)” on page 168 for more
detailed information.
WARNING!
Risk of insufficient ventilation
The displayed spontaneous minute volume
(MV
SPON) indicates the volumes of the patient's
breathing and the mechanical breathing
support. If the mechanical breathing support is
triggered by small tidal volumes of the patient, a
major portion of the spontaneous minute
volume is not achieved by the patient's
breathing but the mechanical breathing
support. In this case, MV
SPON indicates a high
value although the actual spontaneous minute
volume is very low.
Do not make therapy decisions based solely on
the displayed value of MV
SPON.
V T
(PLAT - PEEP)
