SpO2 measurement (Optional)
Figure 108 SpO2 parameterThe SpO2 module displays the SpO2 value as well as
the corresponding upper and lower alarm limits and
the pulse rate.
Selecting a sensor
Only OxiMax sensors or Durasensors from Nellcor
must be used (see separate list of accessories).
The OxiMax modules implemented in the Apollo are
only compatible with the OxiMax sensors (purple
probe or white probe for MAX FAST).
Only the DEC-8 or DEC-4 extension lead (purple
plug connector) may be used.
The new sensors are downward-compatible with all
modules already used in the field in older Dräger
machines.
Note the Instructions for Use of the sensors.
1. Select a sensor in accordance with the following
criteria:
– Patient weight
– Patient mobility
– Possible application point
– Perfusion of the patient
– Duration of use
The following table provides a guideline for selecting
specific sensors shown here with their characteristic
values.
99
67
99
92
Sensor type
OxiMax
MAX N
OxiMax
MAX I
OxiMax
MAX P
Durasensor
DS-100 A
OxiMax
MAX A
OxiMax™
MAX R
OxiMax
MAX FAST
Age group
Neonates/
Adults
Infants Children Adults
Weight of
the patient
<6.6 to
>88 lb
(<3 to
>40 kg)
2.2 lb to 44 lb
(1 kg to
20 kg)
22 lb to 110 lb
(10 kg to
50 kg)
>88 lb
(>40 kg)
>66 lb
(>30 kg)
>110 lb
(>50 lb)
>88 lb
(>40 kg)
Duration
of use
Short and long-term monitoring Short-term
monitoring
Short and long-term monitoring
