Configuration
Instructions for Use Apollo SW 4.5n 205
Part Number: 9053586, 3rd edition
– Tidal Volume
auto: A suitable scale is selected automatically in
accordance with the set age:
– <1 year: 50 mL
– 1 to 2 years: 150 mL
– >2 years to 10 years: 500 mL
– >10 years: 1000 mL
Units
See 2 in Figure 126.
Gas monitoring
See 3 in Figure 126.
Optional parameters
See 4 in Figure 126.
Units Factory setting
CO
2: mmHg, Vol%, kPa mmHg
P
AW: hPa, mbar, cmH2OcmH2O
supply pressure: kPa, MPa,
bar, psi
psi
agents: Vol%, kPa Vol%
weight: kg, lbs. lbs.
Parameter Factory setting
MAC display: yes/no yes
Age corrected: yes/no yes
See page 166 for a detailed description of the MAC
definition and calculation.
Parameter Factory setting
SpO
2: yes/no Automatic setting
Option available: yes
Option not available: no
For a detailed description of SpO
2 monitoring, see
page 178.
