16 Maintenance
394
8
Carefully place the old waste toner container into the empty box.
If you have a used waste toner container no longer needed, contact your local Fuji Xerox representative for its
disposal.
9
Close the right door.
Replacing Drum Cartridges
The device displays a message when a drum cartridge needs to be replaced. When the
message is displayed, replace the drum cartridge.
Locate the position of the indicated drum cartridge (R1, R2, R3, or R4), and replace the
drum cartridge.
If you continue to use without replacing the drum cartridges after the message is displayed,
the device will stop after printing about 12,000 pages.
When replacing a drum cartridge, clean the LED printhead with the supplied cleaning bar to
prevent inconsistencies in density or color in outputs.
Do not expose drum cartridges to direct sunlight or strong light from indoor fluorescent lighting. Do not touch
or scratch the surface of the drum. Doing so may result in unsatisfactory printing.
The remaining page yield is applicable when A4 paper LEF ( ) is used. The value is an estimate and varies
depending on the conditions such as the paper size, the paper orientation, the number of pages continuously
print, and the device operating environment.
Images output from the device may get dirty after the message appears on the touch screen.
When replacing the drum cartridge, tap [Device] on the Home screen then [Supplies] to check the current
status for the drum cartridge even when the touch screen is lit.
1
Make sure that the device is not operating, and open the right door.
2
Pinch the latch and then lower the top of the waste toner container and lift it away from
the main unit.
To Next Page
