ECG
Asecuredstresslooppreventsleadwirerotationabouttheelectrodesnap,
leadwiretuggingattheelectrode,andECGartifact.
3-leador5-leadECGelectrodeplacement
Fora3-leadwireelectrodeplacement,theR/RA,L/LA,andF/LLelectrodesshould
beused.
IEC
AAMI/AHA
Electrodeplacement
R(red)RA(white)Justbelowtherightclavicle.
L(yellow)LA(black)Justbelowtheleftclavicle.
UserdenedC1-C6
(Indicatedas1inthe
electrodeplacement
graphic.)
UserdenedV1-V6
(Indicatedas1inthe
electrodeplacement
graphic.)
Forthe5-leadplacement,placethe
precordialelectrodeaccordingtothe
physician'spreference.
N(black)
RL(green)
Lowerrightedgeoftheribcage.
F(green)
LL(red)Lowerleftedgeoftheribcage.
6-leadECGelectrodeplacement
NOTE
A6-leadwirecableshouldbeusedfor12RL
™
monitoring.
PositiontheCa/VaelectrodeintheC1/V1positionandplace
theCb/VbelectrodeintheC5/V5position.Theleadwire
2094480-001CARESCAPEONE101
