GE CARESCAPE ONE User Manual

Cleaningandcare
WARNING
Neveruseconductivesolutions,oxidizingcompounds,wax,or
waxcompoundstocleandevices,cablesorleadwires.
Cleaningcautions
CAUTION
Donotapplypressurizedairorgastoanyoutletortubing
connectedtothemonitor.Pressuremaydestroysensitive
elements.
Permitteddetergents
Thefollowingpermitteddetergentscanbeusedtocleanthedeviceandother
non-appliedpartsunlessthereareseparatepart-specicinstructions.Non-applied
partsrefertothosepartsofthesystemthatarenotindirectcontactwiththepatient
(e.g.,CARESCAPEDockF0).
●Water
●EnzymaticorneutralpHdetergents
Cleaningpointstonote
●WarrantydoesnotcoveranydamagescausedbyusingotherthanGEapproved
substancesandmethods.
●GEmakesnoclaimsastotheefcacyofthelistedsubstancesormethodsto
controlinfection.
●Yourhospitalguidelinespermitting,allcleaninganddisinfectionactivitiescan
becarriedoutatthebedside.
●Donotletliquidpoolaroundconnectionpins.Ifthisshouldhappen,blotdrywitha
soft,lint-freecloth.
●Donotuseexcessivedryingtechniques,suchasoven,forcedheat,orsundrying.
●Donotspraycleanerdirectlyonthedisplayscreen.
●Neverconnectanydeviceorappliedparttoapatientuntilitisthoroughlydry.
●Ifyoudiscoveranysignsofdeteriorationordamageinthedevice,discontinueits
use.
Settingthetouchscreenoffforcleaning
Youcanlockthetouchscreenwhenyouneedtocleanthescreen.
1.Pressthetouchscreenlockkey
tolockthedisplay.
2.Pressthetouchscreenlockkeyagaintounlockthedisplay.
Generalcleaninginstructions
Followtheseinstructionstocleanthedeviceandothernon-appliedpartsunlessthe
otherpartsprovidepart-specicinstructions.Non-appliedpartsrefertothosepartsof
thesystemthatarenotindirectcontactwiththepatient(e.g.,CARESCAPEDockF0).
Beespeciallycarefulwhencleaningthedisplay.
1.Removeallcablesandthebattery,andclosethebatterydoor.
2.Dampenasoftlint-freeclothwithoneofthepermitteddetergents.
200CARESCAPEONE2094480-001
CARESCAPE ONE User Manual DRAFT 26 October 2017

GE CARESCAPE ONE Specifications

General

Category	Medical Equipment
Manufacturer	GE Healthcare
Model	CARESCAPE ONE
Display Size	10.1 inches
ECG	Yes
SpO2	Yes
NIBP	Yes
Temperature	Yes
Respiration	Yes
Parameters	ECG, SpO2, NIBP, Temperature, Respiration
Device Type	Patient Monitor
Connectivity	Bluetooth
Operating Temperature	0° to 40°C (32° to 104°F)
Storage Temperature	-20°C to 60°C (-4°F to 140°F)
Humidity	15 to 95% RH, non-condensing
Display Type	Touchscreen LCD
