ECG
labelsfortheCa/VaandCb/Vbleadsarewhite(IEC)orbrown
(AAMI/AHA).The12RLshouldbeusedforadultpatientsonly.
IEC
AAMI/AHA
Electrodeplacement
R(red)RA(white)Justbelowtherightclavicle.
L(yellow)LA(black)Justbelowtheleftclavicle.
Ca/C1(white)Va/V1(brown)
4
th
intercostalspace,rightsternalborder.
Cb/C5(white)Vb/V5(brown)LeftanterioraxillarylineatC4/V4level.
N(black)
RL(green)
Lowerrightedgeoftheribcage.
F(green)
LL(red)Lowerleftedgeoftheribcage.
10–leadECGelectrodeplacementforcardiacmonitoring
IEC
AAMI/AHA
Electrodeplacement
R(red)RA(white)Justbelowtherightclavicle.
L(yellow)LA(black)Justbelowtheleftclavicle.
102CARESCAPEONE2094480-001
