Impedancerespiration
Lead
Description
LeadIBestfordetectingthoracicbreathing,butismoresusceptibleto
cardiogenicartifact.
LeadIIEquallygoodatdetectingthoracicorabdominalbreathing,butis
moresusceptibletocardiogenicandmotion(head,neck,orarm)
artifact.
LeadRL-LLBestatdetectingabdominalbreathingandisnotassusceptibleto
cardiogenicormotionartifact.
Notavailablefor3-leadmeasurement.
EventhoughthesameelectrodesareusedforECGandrespirationmonitoring,itis
possibletogetaleadfailmessageforrespirationwithoutoneforECG.Theimpedance
maybetoohighforrespirationdetection,buttheelectrodeisstillgoodforECG
detection.
RespirationleadIelectrodeplacement
ECGleadIforupperchestbreather
IEC
AAMI/AHA
Electrodeplacement
R(red)RA(white)Justbelowtherightclavicle.
L(yellow)LA(black)Justbelowtheleftclavicle.
RespirationleadIIelectrodeplacement
ECGleadIIforchestorupperabdominalbreather
IEC
AAMI/AHA
Electrodeplacement
R(red)RA(white)Justbelowtherightclavicle.
F(green)
LL(red)Lowerleftedgeoftherib
cage.
