GE CARESCAPE ONE User Manual

ECG
IEC
AAMI/AHA
Electrodeplacement
N(black)
RL(green)
Lowerrightedgeoftheribcage.
F(green)
LL(red)Lowerleftedgeoftheribcage.
Ca/C1(white)Va/V1(brown)
4
th
intercostalspace,rightsternalborder.
C2(white/yellow)V2(brown/yellow)
4
th
intercostalspace,leftsternalborder.
C3(white/green)V3(brown/green)MidwaybetweenC2/V2andC4/V4.
C4(white/brown)V4(brown/blue)
5
th
intercostalspace,mid-clavicularline.
Cb/C5(white/black)Vb/V5
(brown/orange)
LeftanterioraxillarylineatC4/V4level.
C6(white/purple)V6(brown/purple)Mid-axillarylineatC4/V4andCb/C5/Vb/V5
levels.
Standardresting10–leadECGelectrodeplacement
IEC
AAMI/AHA
Electrodeplacement
R(red)RA(white)Rightdeltoidorwrist.
L(yellow)LA(black)Leftdeltoidorwrist.
N(black)
RL(green)
Rightthighorankle.
F(green)
LL(red)Leftthighorankle.
Ca/C1(white)Va/V1(brown)
4
th
intercostalspace,rightborderofthe
sternum.
C2(white/yellow)V2(brown/yellow)
4
th
intercostalspace,leftborderofthe
sternum.
C3(white/green)V3(brown/green)MidwaybetweenC2/V2andC4/V4.
C4(white/brown)V4(brown/blue)
5
th
intercostalspace,mid-clavicularline.
2094480-001CARESCAPEONE103
CARESCAPE ONE User Manual DRAFT 26 October 2017
